Creating a Versatile Ventoy USB Drive for Your Homelab

I build multi-boot USB sticks so I do fewer reinstalls and more tinkering. This guide shows how I make a Ventoy USB drive, the hardware I pick, the exact commands I run, and how I test the result. Follow the steps and you will have a single stick that holds rescue toolkits, Linux live environments, OS installers and other utilities.

Getting Started with Ventoy USB Drive

Ventoy is a simple idea. Install a tiny boot loader on a USB device and then copy ISO files onto the stick. At boot you pick an ISO from a menu. There is no repeated formatting. That makes it ideal for rescue toolkits and a library of installers.

What to buy

• Size: 32 GB minimum for a few ISOs, 128 GB if you want many installers and live images. I use 128 GB for a mixed kit that includes several Linux live environments and a couple of Windows installers.
• Speed: pick USB 3.0 or better. Random I/O matters less than sustained read speed for ISOs, but a good flash controller helps when copying many files.
• Type: a USB-A stick is fine. A small NVMe or SATA SSD in an external enclosure works if you want more space and durability.

Prepare your workstation

• Backup any data on the target drive. Ventoy will normally overwrite partitions.
• Identify the device name. Linux: lsblk or sudo fdisk -l. macOS: diskutil list. Windows: use Disk Management or diskpart.
• Unmount the drive. On Linux sudo umount /dev/sdX*.

Why this matters

• Picking the wrong device erases the wrong disk. A quick lsblk check prevents that.
• Legacy BIOS firmware can have limits on large USB drives. If you need to boot very old hardware, keep at least one small stick reserved for legacy-only machines.

Creating a Multi-Boot USB with Ventoy

Download and install

1. Get the latest release from the Ventoy project and extract it. The Linux installer script is Ventoy2Disk.sh. The script supports commands like -i to install and -u to update. I use the default secure boot support unless I have a reason not to. See the official install notes for options and switches before you run the script: https://www.ventoy.net/en/doc_start.html
2. On Linux, run (replace /dev/sdX with the device you confirmed earlier):
   • sudo bash Ventoy2Disk.sh -i /dev/sdX
   • If Ventoy is already present and you want a clean overwrite, use -I.
3. On Windows use the Ventoy2Disk.exe GUI and pick the drive.

Options worth noting

• Use -g if you want GPT partitioning instead of MBR.
• The -s option controls secure-boot support. Ventoy supports secure boot, but some custom ISOs or tools require it off.
• There is a non-destructive mode for some installs, but I do a clean install unless I need to preserve data.

Copying ISOs

• Once Ventoy is on the stick you will see one exFAT partition labelled Ventoy. Simply copy ISO files onto that partition like any normal file.
• File names can be descriptive. I prefix with short tags: rescue-SystemRescue.iso, live-ubuntu-24.04.iso, installer-windows-11.iso.
• Typical collection: SystemRescue or Hiren for rescue toolkits; Ubuntu, Fedora and Arch for Linux live environments; Windows 10/11 ISOs for OS installers.

Persistence and extras

• For persistent live sessions use Ventoy plugins and the ventoy.json configuration file. Create a directory /ventoy and drop a ventoy.json that configures persistence for particular ISOs.
• For custom menus or scripts use the ventoy/scripts folder. I keep a small README on the Ventoy partition that documents what is on the stick.
• If you use Windows installer ISOs, store any driver packs or answer files alongside the ISO. Keep licensing rules in mind for any Microsoft installers or activation scripts; follow the software licence terms.

Testing the multi-boot USB drive

• First test in a VM. QEMU can boot a USB device directly. This catches obvious boot failures before you touch physical hardware.
• Then test on real kit. Try both UEFI and legacy boot modes if you expect to use both. If a machine refuses to boot, check BIOS settings and the active partition flag for legacy BIOS on older systems.
• Try a rescue toolkit image and a live Linux image. Confirm keyboard, network and disk access inside the live environment.
• If an ISO fails, check the Ventoy compatibility list and experiment with the ISO – some old ISOs need workarounds.

Troubleshooting tips

• If a legacy BIOS refuses to boot a large Ventoy drive, split images across a second smaller stick for that machine. Some older firmware has limits around 137 GB.
• If Secure Boot blocks an image, either disable Secure Boot for testing, or enable Ventoy secure boot support at install and add required keys.
• Old ISOs that only boot in legacy mode sometimes require setting the first partition active; use parted or diskpart to change the flag.

Practical example: my personal kit

• On a 128 GB Ventoy USB drive I keep:
  • rescue-SystemRescue-9.06.iso
  • live-ubuntu-24.04-desktop.iso
  • live-debian-12.iso
  • installer-windows-11-english.iso
  • a small utilities folder on the data partition for scripts, notes and driver packs
• I name ISOs with clear prefixes and maintain a README.txt listing versions and checksum sources. That saves time when I need to reinstall or diagnose a server.

Final checks and maintenance

• Keep Ventoy up to date. The update command in the package will replace the boot binaries without touching your ISOs.
• Periodically verify ISO checksums, especially for installers and rescue tools.
• Keep at least one minimal stick for firmware-level tasks if you support old servers.

Key takeaways

• Pick a fast, suitably sized stick. 128 GB covers most kits.
• Use Ventoy2Disk.sh -i /dev/sdX for Linux installs and read the install options first: https://github.com/ventoy/Ventoy
• Copy ISOs directly, use ventoy.json for persistence, and test in both VM and hardware.

That gets you a practical, durable Ventoy USB drive that serves as a rescue kit, a set of live environments and an installer library.
